During the post World War II era, “keying” became a standard method for improving drawing clarity through text reduction within the drawing block. A “keyed” note consisted of an alphanumeric indicator symbol and leader line with a legend of those symbols and the full text notes located elsewhere on the drawing sheet.

What is the purpose of construction documentation?

What is the Purpose of Construction Documents? The purpose of construction documents is to get the design built. These are contract binding documents which describe precisely how the design shall be built: methods, materials, building systems, components.

What should be included in the construction documents?

The Construction Documents contain contract forms, conditions of the contract, specifications, and drawings. Bidding requirements are also produced during this phase. Stringent contractor qualifications are delineated, ensuring that only contractors with a proven track record will be prequalified to bid.

What are the 5 major architectural drawings?

• Floor plan.
• Site plan.
• Elevation.
• Cross section.
• Isometric and axonometric projections.
• Detail drawings.
• Presentation drawings.
• Survey drawings.

What is construction documents in architecture?

What Are Construction Documents? A set of construction documents is a set of drawings that an architect produces during the design development phase of a construction project. … An architect must produce two sets of construction drawings that specify every detail of their final design.

What are three types of construction documents?

Generally, there are three different types of construction specifications found in contracts: prescriptive specifications, performance specifications, and proprietary specifications.

What is construction documentation?

Construction documents, as defined by CSI, are “the written and graphic documents prepared for communicating the project design for construction and administering the construction contract.” They consist of the drawings, specifications, contracting requirements, procurement requirements, modifications and addenda, and …

What drawings do architects use?

• Site Plans. …
• Elevation. …
• Cross Section. …
• Isometric and axonometric projections. …
• Detail Drawings.
• Concept drawings and sketches. …
• Electrical drawings. …
• Hand drawings.

What are the 6 types of construction drawings?

• Plans.
• Interior and exterior elevations.
• Building and wall sections.
• Interior and exterior details.
• Schedules and room finishes.
• Framing and utility plans.

What makes a good architectural drawing?

See the light. One of the most effective methods of making your drawings appear three dimensional is to consider how light works. A careful handling of light, shadow and tone can help give definition to form. … For objects and buildings, you have a light side, a shadow side and a cast shadow of a form.

Article first time published on

How do you label architectural sections?

1. Building Section. Top Line = Drawing Number. …
2. Wall Section. Top Line = Drawing Number. …
3. Detail Section. Top Line = Drawing Number. …
4. Exterior or Building Elevation. Top Line = Drawing Number. …
5. Plan Detail Call Out. Top Line = Drawing Number. …
6. Column Grid Call Out. …
7. Revision Cloud. …
8. Wall or Partition Tag.

What are the two components of construction documents?

The two major components that make up the contract documents are the drawings and the project manual.

What are specifications in construction?

According to the Dictionary of Architecture & Construction a specification is, “a written document describing in detail the scope of work, materials to be used, methods of installation, and quality of workmanship for a parcel of work to be placed under contract; usually utilized in conjunction with working (contract) …

What is the difference between design documents and construction documents?

Construction Documents: The right information to the right people. Schematic Design sets up the general idea for a project and Design Development focuses and refines it. Construction Documents fill in all the details.

What are AIA construction documents?

An AIA is a document that contains completed contract billing throughout the project; this document was created mainly to assist architects working on a construction project to be paid for the work completed on the project.

What are the types of construction documents drawings?

• 1 Architectural Drawings: This is one of the types of construction drawings. …
• Structural Drawings: …
• Electrical Drawings: …
• Plumbing and Sanitary Drawings: …
• Finishing Drawing:

What are 5 methods of specification?

• Requirement Specifications. Documentation of a business need. …
• Design Specifications. …
• Material Specifications. …
• Standard Specifications. …
• Interface Specifications. …
• Test Specifications. …
• Performance Specifications. …
• Quality Specifications.

What are the types of specifications?

• General Specifications.
• Detailed Specifications. a. Standard Specification. b. Special Specification.

What are material specifications?

Material Specifications means the description of the Material, including requirements, tolerances, shelf life, specifications, suppliers and safety data, that are set forth in Exhibit D.

What are the types of architectural plans?

• Floor Plans. Floor plans are essential to any interior design or architecture project. …
• Site Plans. …
• Reflective Ceiling Plan. …
• Millwork Drawings. …
• Exterior Elevations. …
• Interior Elevations. …
• Landscape Plans.

How many drawings are there in architecture?

7 Types of Architectural Drawings.

Is code for architectural drawings?

1- IS 962: Code of practice for architectural and building drawings.

What is Section in architecture?

One particularly useful type of drawing is what’s called an architectural “section.” It’s the drawing of a vertical cut through a building or an area of a building. The purpose of a section is to show, graphically, the main volumes of the building and the main building material components.

What is the typical size of architectural drawings?

What is the standard blueprint paper size? Blueprints and house plans will come in several standard sizes. Two of the most common architectural drawing sizes are 18” x 24” and 24” x 36”, but the Business Box also prints construction plans of 36” x “48” sizes.

What skills does a architect need?

• Numerical skills. …
• Creative skills. …
• Design skills. …
• Legal knowledge. …
• Communication skills. …
• Teamwork skills. …
• Commercial awareness. …
• Artistic skills.

How many qualities a drawing should have?

Drawing requires dexterity, good spatial sense, and creativity. It requires us to take things abstractly. One is required to make measurements.

How can I improve my architecture drawing skills?

1. Adopt the “Hit-Go-Hit” technique. …
2. Don’t move your pen/pencil by bending your wrist or elbow. …
3. Incorporate the use of pen weight. …
4. Intersect your lines at the corners. …
5. Trace isn’t precious.

How do you label a section drawing?

1. title of the drawing.
2. drawing number.
3. scale of drawing.
4. paper size.
5. drawing sheet number of referenced drawing (where applicable, ie sections, elevations.)

What is Section AA in drawing?

The cutting plane is represented by a cutting plane line. The cutting plane line is defined as A-A, and the section view is defined as view A-A. Figure 4-42. All surfaces directly visible must be shown in a section view.

Which documents are the most important for the construction process and why?

The drawings and building plans are the most important documents for your construction project.

What is the contents of building drawing?

Drawings Structural drawings must show the size, section, and relative locations of all of structural members in a building. Foundation plans. Framing plans for all levels at and above ground. Schedules for the structural members, including foundations, beams, slabs, columns, and walls.
