For most jobs, you’ll need a loader or a 3-point hitch and some implements. … To use those implements, you’ll need to know the difference between the 3-point hitch categories.

What is a cat 0?

Garden Tractor. … NOTE: CAT-0 is defined as Tractor Power up to 20 hp (15 kW)

What is considered a Category 1 tractor?

Category 1 is very, very common and typically you’re gonna see Category 1 on tractors under about 50 horsepower. … This is typically used on tractors between about 50 and 150 horsepower or so, although there are always gonna be some exceptions in those ranges.

What is a cat 1 hitch on a tractor?

Category 1 hitches are generally found on subcompact and compact tractors from 20 hp up to about 50 hp. The top link pin measures 3/4″ in diameter and the lift arm holes are 7/8″. The spacing between the lift arms is approximately 26″ while the mast height is 15″.

What is the difference between a Cat 1 and Cat 2 3 point hitch?

Category 0 Hitch For tractors with up to 20 horsepower. Category 1 Hitch For tractors with 20 to 50 horsepower. Category 2 Hitch For tractors with 50 to 90 horsepower. Long days can seem even longer when you aren’t comfortable.

What is a Category 1 quick hitch?

This 3-point quick hitch is used for the easy attachment and release of 3-point implements and equipment. The lift arm spacing on this category 1 tractor hitch is 27-1/4 in. The distance between the lift arms and the top link is adjustable and ranges from a minimum of 15 in. to a maximum of 18-1/4 in.

Can Cat 1 implements be used on CAT 2 tractor?

If you wanted to stay with your current cat 1 implements, probably should have bought a cat 1 tractor. As 56FordGuy said, you have to be careful using cat 1 implements behind a cat 2 tractor. They typically just are not built to take the stresses that a cat 2 tractor can put on them.

What is a Category 2 three-point hitch?

Category 2 hitches are also common, albeit on slightly more high-powered tractors with horsepower ranging from 40 to 125. A Category 2 hitch increases the top link pin diameter to 1 inch and the lift arm pins to 1 1/8 inch. The spacing between the arms increases to approximately 32 inches.

What size are Cat 0 pins?

Category 0 Top Link Pin 4-7/16″ This pin has a hole at the end that is 9/32 inches in diameter. It has a usable length of 3 inches and an overall length measuring 4-7/16 inches. The stable top link pin has a diameter measuring 5/8 inches.

What are the different class hitches?

Hitch ClassCommon ApplicationsGTW Capacity (lbs.)Class 1Cars and crossoversUp to 2,000Class 2Cars, crossovers and minivansUp to 3,500Class 3Crossovers, vans, SUVs and trucksUp to 8,000Class 4Trucks and SUVsUp to 10,000

Article first time published on

What is a tractor 3-point hitch used for?

The primary benefit of the three-point hitch system is to transfer the weight and resistance of an implement to the drive wheels of the tractor. This gives the tractor more usable traction than it would otherwise have, given the same power, weight, and fuel consumption.

What category 3 point hitch is on a Kubota BX?

The BX-Series feature a sturdy, hydraulically controlled Category I 3-point hitch that allows you to attach a wide variety of rear implements.

What size is CAT 1 3 point hitch?

CategoryHitch pin sizepower119 mm (3/4″)15-35 kW (20-45 hp)225.5 mm (1″)30-75 kW (40-100 hp)331.75 mm (1 1/4″)60-168 kW (80-225 hp)445mm (1 3/4″)135-300 kW (180-400 hp)

How wide is a 3 point hitch?

Category 2Category 3Lower link hole diameter28.70 mm (1.13 in.)37.34 mm (1.47 in.)Lower hitch point Span (1)825 mm (32.48 in.)964.95 mm (37.99 in.)Width of ball (2)44.96 mm (1.77 in.)44.96 mm (1.77 in.)Pin centerline – Lower to upper (3)610.11 mm (24.02 in.)685.04 mm (26.97 in.)

How much weight can a three-point hitch lift?

Category 1 3-point hitch for maximum implement versatility. Category 1 hitch allows quick hookup of 3-point hitch implements, especially when equipped with the iMatch™ Quick Hitch and/or iMatch AutoHitch™. The lift capacity of the 3-point hitch is 1356 pounds (615 kg) measured at 24 in. behind the hitch balls.

Are Titan Implements quick hitch compatible?

With the Category 1 and 2, 3 Point Quick Hitch by Titan Attachments®, you can easily switch between implements that connect to your tractor’s 3 Point hitch. … CATEGORY 1 OR 2, 3-POINT HOOKUP: This adapter is designed to convert your Category 1 or 2, 3 Point hitch into a quick hitch.

How do you determine top link length?

Top link. How to determine the best overall working length for your hydraulic top link is to get the true mid stroke pin-pin distance. The best way to do this is to have your tractor hitched up to your box blade (as an example) have the implement level with the ground front-back and side-side.

What is a Category 4 drawbar?

This Category 4 adjustable swinging drawbar allows 2-in. pin size (anti-rotational square-head design) with a maximum static vertical load of 4900 lb. Applications for Category 4 drawbar include: large-sized, heavy-load drawn chisel plows, field implements, or maximum-loaded grain carts.

How do I know if my hitch is Class 1 or 2?

Class I and Class II hitches both have a 1-1/4 inch receiver opening. The difference is that a Class I hitch has a lower tongue weight rating, usually 200 pounds and a lower towing rating, usually 2,000 pounds. A Class II hitch usually has a tongue weight rating of 350 pounds and a towing rating of 3,500 pounds.

What can I tow with a Class 1 hitch?

A class 1 trailer hitch is ideal for adding cargo space to your vehicle or providing a secure way of transporting your bikes. It can also be used to tow a variety of small, light-duty trailers, such as a kayak hauler, teardrop camper or small utility trailer.

How do I know what class hitch I have?

Hitch classes are separated by their maximum weight capacity rating and receiver opening size. Classes range from I to V, and each class has its own unique capacity and applications. To find: Read the label on your hitch, or measure the size of the opening.

Does a 3 point hitch float?

A 3 point hitch is always in a “float” mode it does not have any down pressure. Depending on your tractor it may have position control, were the downward travel is controlled by the 3 point lever, the futher it is moved the lower the lift arms will drop.

Why won't my 3 point hitch won't lift?

When a tractor 3 point hitch doesn’t operate properly, many times low fluid, a clogged hydraulic filter, or low or contaminated hydraulic fluid is the cause of the problem. … If the loader does not operate correctly, then there is a problem is likey related to the hydraulic pump.

Does the Kubota BX23S have a 3 point hitch?

Three-point hitch (3PH) lift capacity is 680 lbs measured at 24” behind pin, but since the BX23S is a TLB, the top and lower link arms are optional. There are two loaders available – the LA340 (pin-on) and the LA340S quick attach (Swift-Tach). … Lift capacity is 613 lbs (at pivot pin) to a max height of 71”.

How much does a Kubota BX2380 cost?

2020 Kubota BX2380 • $12,050 Quality, innovation and easy-to-use design – that’s a Kubota.

What horsepower is a Kubota BX2380?

Bore2.9 in (7 cm)Engine MakeKUBOTAEngine ModelD902Engine TypeLiquid-cooled, 3-cylinder dieselGross Power23 hp (17 kw)
