The calculated OCA/H is the height of the highest obstacle, or equivalent missed approach obstacles, plus an aircraft-related allowance. In assessing these obstacles, the operational variables of the aircraft category, approach coupling, category of operation, and missed approach climb performance are considered.

What is an obstacle clearance height defined as?

Obstacle clearance altitude (OCA) or Obstacle clearance height (OCH): The lowest altitude or the lowest height above the elevation of the relevant runway threshold or the aerodrome elevation as applicable used in establishing compliance with appropriate obstacle clearance criteria.

What is MEA and MOCA?

MEA is the altitude that will provide obstacle clearance, as well as ensuring navaid signal coverage for the airway. MOCA is the lowest altitude you can go down to with legal IFR separation. A good example of when MEA and MOCA differ would be flying through mountains.

What is the obstacle clearance altitude of military aircraft *?

Terrain ElevationObstacle Clearance3000 ft – 5000 ft (900 m – 1500 m)1500 ft (450 m)Greater than 5000 ft (1500 m)2000 ft (600 m)

When determining the OCA for a precision approach obstacle clearance height is referenced to?

Obstacle clearance altitude is referenced to mean sea level or in the case of non-precision approaches to the aerodrome elevation or the threshold elevation if that is more than 2 m (7 ft) below the aerodrome elevation. An obstacle clearance height for a circling approach is referenced to the aerodrome elevation.

What is minimum obstacle clearance in aviation?

Minimum Obstacle Clearance Altitude, or MOCA, is the lowest published altitude in effect between fixes on VOR airways or route segments that meets obstacle (like a building or a tower) clearance requirements for the entire route segment.

What is the difference between DA and MDA?

As the names suggest, DA is a decision point while MDA is the lowest altitude allowed without visuals. The difference between DA vs MDA is reflected in the regulations, Practical Test Standards (PTS, soon Airman Certification Standards) and TERPS.

Does MRA provide obstacle clearance?

MINIMUM RECEPTION ALTITUDE (MRA)- The lowest altitude at which an intersection can be determined. (Refer to 14 CFR Part 95.) The minimum altitude specified in 14 CFR Part 91 for various aircraft operations. Altitudes depicted on approach charts which provide at least 1,000 feet of obstacle clearance for emergency use.

What is OCA and OCH in aviation?

OCA and OCH are the Obstacle Clearance Altitude and Obstacle Clearance Height. The difference between them is obviously the Altitude and Height. The OCA is based on the altitude above sealevel and the OCH is based on the Height above threshold or aerodrome elevation.

What is the meaning of DGCA?

The Directorate General of Civil Aviation (DGCA) is the regulatory body in the field of Civil Aviation, primarily dealing with safety issues. It is responsible for regulation of air transport services to/from/within India and for enforcement of civil air regulations, air safety, and airworthiness standards.

Article first time published on

How do you find the minimum holding altitude?

The minimum holding level provides a clearance of at least 1000 ft (300 m) above obstacles in the holding area, a value (as given in the table) above obstacles in the buffer area. The minimum holding altitude to be published shall be rounded up to the nearest 100 ft, or 50 m, as appropriate.

What is MCA in aviation?

Minimum Crossing Altitude (MCA). An MCA is the lowest altitude at certain fixes at which the aircraft must cross when proceeding in the direction of a higher minimum en route IFR altitude.

Is the MOCA higher than the MEA?

You are right. Within 22 nautical miles of the VOR, there is no practical difference between an MEA and a MOCA.

Can you fly below mea?

You still might be cleared below that MEA if ATC has lower minimum IFR altitudes or minimum vectoring altitudes available in that area, but those altitudes are not typically published on charts that pilots use. * You would just ask for a lower altitude, and the controller could clear you to the appropriate MVA or MIA.

What is a minimum vectoring altitude?

Minimum Vectoring Altitude (MVA) is the lowest altitude, expressed in feet AMSL (Above Mean Sea Level (MSL)), to which a radar controller may issue aircraft altitude clearances during vectoring/direct routing except if otherwise authorized for radar approaches, departures and missed approaches.

What is MDA in aviation?

The Aeronautical Information Manual) (AIM) defines minimum descent altitude, or MDA, as “the lowest altitude, expressed in feet above mean sea level (MSL), to which descent is authorized on final approach, or during circle-to-land maneuvering, in execution of a standard instrument approach procedure (SIAP) where no …

What is derived decision altitude?

The CDFA technique adds an altitude pad to account for the aircraft’s tendency to go below the altitude at which the missed approach is initiated, usually due to autopilot reaction time. The new altitude, that resulting from the addition of this pad to the MDA, is known as the Derived Decision Altitude (DDA).

What is decision altitude?

Definition. The Decision Altitude (DA) or Decision Height (DH) is a specified altitude or height in the Precision Approach or approach with vertical guidance at which a Missed Approach must be initiated if the required visual reference to continue the approach has not been established. (

Are MDA AGL or MSL?

All approach minimum altitudes, whether MDA or DA, are expressed in both MSL and AGL altitudes. As stated above, DA is read from the altimeter…it gives you the direct answer to “when do I reach minimum altitude?” in flight.

Why do we add 50 feet to our MDA minimums?

Most ATOs add 50 feet to the MDA to take into account the inertia of the aircraft, but this is an SOP item not a regulatory requirement. Some ATOs will add 50 feet to a precision DA for PEC (pressure error correction) unless the AFM states a different PEC.

What's the difference between decision height and decision altitude?

A decision height (DH) is measured above ground level. A decision altitude (DA) is measured above mean sea level. Both are used for precision approaches. DH and DA are given at the destination airport and are established to allow enough time to safely reconfigure a private plane to climb and initiate a missed approach.

What is the difference between minimum safe altitude and minimum sector altitude?

In USA, Minimum Sector Altitude is also known as Minimum Safe Altitude, MSA is altitude depicted on an instrument chart and identified as the minimum safe altitude which provides 1000ft of obstacle clearance within a 25NM radius from the navigational facility upon which the MSA is predicated.

What is the minimum safe altitude to fly anywhere?

An altitude of 500 feet above the surface, except over open water or sparsely populated areas. In those cases, the aircraft may not be operated closer than 500 feet to any person, vessel, vehicle, or structure.

When flying a northbound IFR flight on V257 What is the minimum crossing altitude at DBS Vortac?

When flying a northbound IFR flight on V257, what is the minimum crossing altitude at DBS VORTAC? 8,600 feet.

What is a CDFA approach?

Definition of CDFA. CDFA is a technique for flying the final approach segment of an NPA as a continuous descent. The technique is consistent with stabilized approach procedures and has no level-off. … This definition harmonizes with the ICAO and the European Aviation Safety Agency(EASA).

What is a circling approach?

A circling approach is the visual phase of an instrument approach to bring an aircraft into position for landing on a runway which is not suitably located for a straight-in approach. (

What is Artcc?

Air Route Traffic Control Centers ( ARTCC ), also referred to as “centers,” are established primarily to provide air traffic services to aircraft operating on an Instrument Flight Rule ( IFR ) Flight Plan within controlled airspace. This service is provided principally during the en route phase.

What is the maximum altitude that Class G airspace will exist?

Class G airspace within the United States extends up to 14,500′ Mean Sea Level (MSL) At and above this altitude is Class E, excluding the airspace less than 1500′ above the terrain and certain special use airspace areas.

What does abeam mean in aviation?

An aircraft is ‘abeam’ a fix, point, or object when that fix, point, or object is approximately 90 degrees to the right or left of the aircraft track. Abeam indicates a general position rather than a precise point.

Are DGCA exams tough?

ExamDifficulty levelApprox, no. of attemptsAviation MeteorologyMedium1-3Technical GeneralHard3-5Air NavigationHard3-5

Which airlines are DGCA approved?

S.NoAirline Name1Air Asia2Air India3Alliance Air4Fly Big
